Plastic (Non-Metallic)
Bag Filter Housings for Liquid Filtration
Plastic filter housings for difficult filtration applications. We offer the heavy duty Eaton-GAF-Hayward Polyline filter housing and a range economically price housings for light duty applications.



Hayward FLV Vessles only
Filter Bag Sizes - Flow rates are based on using a Nominal rated filter bag & a visocity of 1 c.p.
Size Flow Rate Dimensions Flow Area
01 12,000 (lt per hour) 7" dia x 17" long 2.6 sq.ft.
02 24,000 (lt per hour) 7" dia x 32" long (up to 2" ) 5.0 sq.ft.
02 34,100 (lt per hour) 7" dia x 32" long (2-1/2' to 4") 5.0 sq.ft.



Polyline & FLT Vessles only
Filter Bag Sizes - Flow rates are based on using a Nominal rated filter bag & a visocity of 1 c.p.
Size Flow Rate Dimensions Flow Area
01 12,000 (lt per hour) 7" dia x 17" long 2.6 sq.ft.
02 24,000 (lt per hour) 7" dia x 32" long 5.0 sq.ft.



Poly-lite Vessles only
Filter Bag Sizes - Flow rates are based on using a Nominal rated filter bag & a visocity of 1 c.p.
Size Flow Rate Dimensions Flow Area
01 11,400 (lt per hour) 7" dia x 17" long 2.6 sq.ft.
02 16,200 (lt per hour) 7" dia x 32" long 5.0 sq.ft.
